Connecting Rod Boring Machine
Our company is one of the preferred choices of clients for offering Connecting Rod Boring Machine that is vastly demanded for boring of connecting rods of heavy and light duty vehicles. To cater to the varied demands of our patrons, we provide these efficient machines in numerous specifications. Due to the excellent operating speed, ease of operation and energy-efficiency, the series is widely sought after. These precisely engineered using best available technologies and material to render maximum client satisfaction.
|
MODEL |
KMT-80-CR |
|
Min. and Max. Bore center distance of the connecting rod |
80mm- 450mm |
|
Boring spindle speeds |
240,320,470,500,630,1000 RPM |
|
Boring range |
15mm to 140mm |
|
Bottom part traverse crosswise |
50mm |
|
Table movement longitudinal |
300mm |
|
Motor spindle speed |
(Dual speed) HP/KW/0.95/1.7-0.7/1.25 720/1420 rpm |
|
Motor spindle feed |
0.25 HP (D.C) |
|
Length of the machine |
1450mm |
|
Width of the machine |
850mm |
|
Height of the machine |
1850mm |
Special Features
- Reliable performance
- Robustly constructed
- Hassle-free boring application
